Level-Trac 501 Water Column

Brand: Quest-Tec Solutions

The Level-Trac Model 501 probe column features sturdy construction in full compliance with ASME requirements.

The Model 501 Water Column may be used as an independent remote level indicator per ASME PG-60, or as a traditional water column for the mounting of direct reading sight glasses.

All piping connections are to user specifications.
Features
  • Max 2,000 psi
  • Extruded A-105 Column
  • Probe Spacing per Customer’s Requirements
  • Optional Connections for Direct Reading Sight Glasses
  • Piping Connections to Meet Customer Specifications

Specifications

Approvals & Certifications

  • ANAB

Mounting

  • Horizontal Probe Mounting

Pressure Rating

  • psi: 2,000 (kPa: 13,790, bar: 137.9) Steam Working Pressure, 1,100° F

Sensor, Probe Material

  • Zirconium Insulated Probe, Swage Typical Seal
